| Product model | PLPF0280C0-2227R2A |
| Battery Parameters | |
| Cell type | 3.2V/280Ah |
| Cell life | ≥6000@100%DOD, 80%EOL |
| Rated battery capacity | 623.616kWh |
| Battery voltage range | 626.4~846.8V |
| AC Parameters | |
| Rated output power | 250kW |
| AC output current | 360A |
| Rated grid voltage | 400V |
| Grid voltage range | ±15% |
| Rated grid frequency | 50Hz/60Hz |
| Grid frequency range | ±2.5Hz |
| Grid connected power factor | -1 (leading) ~ 1 (lagging) |
| Total harmonic distortion (THDI) | ≤3% (at rated power) |
| Isolation mode | Transformer Isolation |
| System Parameters | |
| Container size (W x H x D) | 6058 X 2896 X 2438mm |
| Humidity range | 0~95% (No condensation) |
| Operating temperature range | -30~60ºC (>40ºC derating) |
| Converter cooling method | Temperature controlled forced air cooling |
| Battery temperature control | Industrial grade temperature controlled air conditioning |
| Fire extinguishing system | Fire protection system + water fire protection (optional) |
| Maximum altitude | 5000m (>3000m derating) |
| Communication protocol | ModBus -TCP / IEC61850 / IEC104 |
