Symbion Energy
1 / 5
* Pre-installed containerized systems (battery + PV input) reduce installation/commissioning time and costs.
* Plug-and-play deployment for rapid setup.
* AI-optimized air-cooling maintains full power at 45°C (IP54 rated).
* Round-trip efficiency (RTE) 3% higher than competitors.
* LFP (LiFePO₄) batteries ensure safety and long cycle life.
* Modular cabinets/containers allow flexible capacity customization (e.g., 100kWh–5MWh).
* Supports on/off-grid operation and parallel deployment (up to 4 units off-grid).
* Reduces energy costs by 30%–70% through peak shaving and solar integration.
* Lower maintenance costs via cloud monitoring and quick-plug design.
* Multi-layer protection: automatic fire extinguishers and PACK-level immersion fire tech.
* Cell-level temperature control (<5°C variation) and strict certifications (IEC/UN38.3).
* Cloud-based remote monitoring, AI energy optimization, and 24/7 fault detection.
* Adaptive charging/discharging strategies maximize ROI.
* Fully automated production lines (air/liquid-cooled PACKs).
* ODM capabilities and GWh-scale project experience.
| BESS Lithium Battery Storage Container (100kWh - 5MWh) | |||
| DC SIDE PARAMETERS | AC SIDE PARAMETERS | ||
|---|---|---|---|
| DC Rated Voltage | 1331.2 V | Rated Output Power | 2500 kW |
| DC Voltage Range | 1164.8 ~ 1497.6 V | Max Output Power | 2750 kVA |
| Rated Energy Capacity | 5015 kWh | Rated On-grid Voltage | 690 Vac |
| Cell Type | LFP 314 Ah | Grid Frequency | 50Hz / 60Hz |
| Battery Cycle | 8000 @ 25°C, 80% DOD | THDi | < 3% |
| GENERAL PARAMETERS | |||
| Cooling Method | Liquid Cooling / AI Air Cooling | Protection Level | IP55 / IP54 |
| Operating Temperature | -20°C ~ 55°C | Max Altitude | 4000m |
| Dimensions (W*H*D) | 6096 * 2438 * 2896 mm | Container Weight | Approx. 43 tons |
| Communication | CAN, RS485, Ethernet | Protocols | Modbus TCP/RTU, IEC 104 |
